Technical description of the burner
4.1 Burner designation
4.2 Models available
4 Technical description of the burner
Designation Voltage Start-up Code
RLS 70 TC 3/380-220/60 Direct 20159363
RLS 100 TC 3/220/60 Direct 20159369
RLS 130 TC 3/220-380/60 Direct 20169069
Class 2 EN267 - Class 3 EN676
Series: R
Size
Fuel: Natural gas
Light oil
Gas oil / Methane
Adjustment:
Electrical supply of the system:
3/400/50
3/230/50
Voltage of auxiliaries:
230/50/60
110/50/60
R LS 70 TC
Emission:
C11 or... Class 1 EN267 - EN676
C22 or MZ Class 2 EN267 - EN676
C33 or BLU Class 3 EN267 - EN676
3/380/50 220/60
BASIC DESIGNATION
EXTENDED DESIGNATION
3N / 400V / 50Hz
3 / 230V / 50Hz
230V / 50-60Hz
110V / 50-60Hz
Heavy oil
E Electronic cam
EV Electronic cam and variable speed (with Inverter)
P Proportional air/gas valve
BP Two stage (light oil) / Proportional valve (gas)
M Mechanical cam
S
L
LS
N
Head:
TC Standard head
TL Extended head
C23 or MX
MX Class 1 EN267 - Class 3 EN676
Flame control system:
FS1
FS2
Standard (1 stop every 24 h)
Continuous operation - only using the flame
detection electrode (ionisation)
FS1
