Riello RS 50/E - Packaging - Weight; Burner Dimensions; Standard Equipment

Technical description of the burner
9
20053677
3.5 Packaging - weight
The burners are skid mounted. Outer dimensions of packaging are
indicated in Tab. E.
The weight of the burner complete with packaging is indicated in
Tab. E.
Tab. E
3.6 Burner dimensions
The maximum dimensions of the burners are given in (Fig. 3).
Inspection of the combustion head requires the burner to be
opened and the rear part withdrawn on the slide bars.
The maximum dimension of the burner when open, without casing,
is give in measurement H.
Tab. F
(1)
Blast tube: short - long (obtainable with the kit)
3.7 Standard equipment
Gas train flange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .No. 1
Flange gasket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .No. 1
Flange fixing screws. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .No. 4
Instruction manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .No. 1
