Rifton Wave - Accessories; Mounting the bathing stretcher on the bath sub-frame; Adjustment of the standing legs; Mounting the bathing stretcher on the shower sub-frame

11
4.1.1 Adjustment of the standing legs
The standing legs of the bath sub-frame are adjusted in the same way as the ba-
thing stretcher standing legs (see Point 3.6).
Prior to use, please ensure that all four legs on the bathing stretcher
are rmly secured on the sub-frame!
4.1 Mounting the bathing stretcher on the
bath sub-frame
Put the bathing stretcher feet into maximum up-
right position (see Point 3.6). Then press the ba-
thing stretcher feet rmly into the adaptors (A) of
the sub-frame until they engage (A).
In order to remove the bathing stretcher, press
the grey levers (B) down one after the other as
shown and lift the bathing stretcher.
B
A
4. Accessories
4.2 Mounting the bathing stretcher on the
shower sub-frame
Press the feet of the bathing stretcher into the
opening (C) of the sub-frame until they engage.
In order to remove the bathing stretcher, press
the grey levers (D) down one after the other and
lift the bathing stretcher.
Prior to use, please ensure that all four
legs on the bathing stretcher are rm-
ly secured on the sub-frame!
C
D
B
