4.3 Mounting the bathing stretcher onto the
transfer sub-frame
Press the grey aps (A) together and raise the
legs upright until they engage audibly.
Then bring the standing legs of the bathing stret-
cher into a completely at position (see Point 3.6)
and hook the bathing stretcher under the hook
(B). Press the bathing stretcher down until it en-
gages audibly under the grey hook (C).
The transfer sub-frame can be adjusted in height.
To do this, simply press the button (D) into the
hole pattern on the standing leg and allow it to
click out again at the required hole pattern posi-
tion. Repeat this adjustment on all four standing
legs.
B
C
4.3.1 Transfers with the transfer sub-frame
Press the grey button (E) and turn the bathing
stretcher towards you.
Pull the transfer sub-frame forward to the inner
edge of the bath and lock the wheel brakes (F)
(see Point 4.4.) Position the user on the bathing
stretcher. Loosen the wheel brakes (F) and turn
the bathing stretcher with the user, whilst you lift
their legs into the bath by pressing the grey but-
ton (E). Push the transfer sub-frame with the user
into the bath. Lock the wheel brakes (F) again.
E
F
F
A
D
The height may only be adjusted when
the product is not in use!
