Projector Knowledge
Projector can input high-definition video signal and composite video signal, and
support stereo audio signal input and output. Please refer to the following figure to
connect the projector and other audio equipment according to your own needs.
1. Level-Stand Adjustment
2. IR receiver
3. Focus Lens
4. Power Switch
5. IR for remote control
6. 3.5mm port for audio output
7. HDMI 1 port
8. USB port
9. AV port
10. HDMI2 port
11. Speaker
12. Cooling window
13. Focus
14. Switch of removable dust cover
15. Removable dust cover
To Next Page
