Shackmaster™ Power 500 DC Power Supply Instruction Manual
Specifications
Rated power 500W
Rated current 35A
Output voltage 13.8V
Ripple 200mVp-p
Input AC voltage 80V to 264V
Input AC frequency 47Hz to 63Hz
AC current (maximum) 5.8A @ 110VAC | 2.9A @ 230VAC
Overvoltage protection Yes
Overvtemperature protection Yes
Overcurrent protection Yes
Short circuit protection Yes
Working temperature range -30°C to +70°C | -22°F to 158°F
Storage temperature range -40°C to +85°C | -40°F to 185°
EMC Emission Class I: Class B, Class II: Class A
Dimension 172mm x 55mm x 185mm
Weight 1.1kg
Acoustic noise ~21 dBa
