3. To edit arbitrary waveform
Press Arb  Edit Wform to open the arbitrary waveform editing menu.
1) Press Mode to select “Sample Rate”.
2) Press HiLevel, use the numeric keyboard to input 4 and select V from the
pop-up menu.
3) Press LoLevel, use the numeric keyboard to input -2 and select V from the
pop-up menu.
4) Press Points, use the numeric keyboard to input 8 and press Sure. At this
point, a -2V level line appears.
5) Press Edit Points to enter the points editing interface.
 Press Edit Points to define the first point. Press Voltage, use the
numeric keyboard to input 4 and select V from the pop-up menu.
 Press Edit Points again, use the numeric keyboard or knob to select
point 2; then press Voltage to input 4V.
 Define the voltage of point 3 to point 8 according to the method
mentioned above.
4. To select waveform
Press Arb  Select Wform  Volatile Wform to select the waveform edited.
5. To enable the output
Press Output1 to turn CH1 output on. At this point, the backlight goes on and
the [CH1] connector outputs arbitrary waveform with the specified parameters.
6. To observe the output waveform
Connect the [CH1] connector to the oscilloscope using BNC cable. Now, you can
observe the waveform via the oscilloscope.
