Chapter 1 Overview RIGOL
DG4000 Performance Verification Guide
1-1
Chapter 1 Overview
Test Preparations
Please ensure that your instrument is in the calibration period (the recommended
period is 1 year) and warm it up for at least 30 minutes under the specified operation
temperature (18℃ to 28℃).
Recommended Test Devices
It is recommended that you use the test devices listed in Table 1-1 or other test
devices with the same performance and specifications for performance verification
tests.
Table 1-1 Recommended Test Devices
Device Performance Requirement Recommended
Frequency
Counter
>10 MHz
Accuracy: 0.1 ppm
Agilent 53131A
Digital Multimeter 6
1
/
2
RIGOL
DM3068
Power Meter
-30 dBm to +20 dBm
Accuracy: ±0.02 dB
Resolution: 0.01 dB
Agilent E4416A
Spectrum
Analyzer
Minimum resolution bandwidth is 10 Hz.
RIGOL DSA1030A
Oscilloscope
Bandwidth: 500 MHz
Rise/fall time measurement function
Overshoot measurement function
RIGOL DS4054
Cable BNC (m) – BNC(m) --
Cable BNC (m) – dual banana plugs (m) --
50 Ω Load 50 Ω/1 W --
Power Sensor -35 dBm to +20 dBm Agilent N8482A
Power Sensor
Cable
Used to connect the power meter and
power sensor
--
Connector N (f) – BNC (m) --
Connector BNC (f)-N (m)
