Appendix RIGOL
DG4000 Performance Verification Guide
7
Spurious Signal Test
Channel: CH1
Output
Frequency
Start
Frequency
Stop
Frequency
A A-0dBm Limit
Pass/
Fail
10 MHz 0 Hz 100 MHz
≤10 MHz: <-65 dBc
>10 MHz: -65 dBc+6
dBc/octave
[1]
50 MHz 0 Hz 150 MHZ
100 MHz
[2]
0 Hz 300 MHz
150 MHz
[3]
0 Hz 500 MHz
200 MHz
[4]
0 Hz 600 MHz
Channel: CH2
Output
Frequency
Start
Frequency
Stop
Frequency
A A-0dBm Limit
Pass/
Fail
10 MHz 0 Hz 100 MHz
≤10 MHz: <-65 dBc
>10 MHz: -65 dBc+6
dBc/octave
[1]
50 MHz 0 Hz 150 MHZ
100 MHz
[2]
0 Hz 300 MHz
150 MHz
[3]
0 Hz 500 MHz
200 MHz
[4]
0 Hz 600 MHz
Note
[1]
: 6dBc/octave means that when the frequency doubles, the specification increases by 6 dBc.
Note
[2]
: Only for DG4202, DG4162 and DG4102.
Note
[3]
: Only for DG4202 and DG4162.
Note
[4]
: Only for DG4202.
