RIGOL Chapter 2 Front Panel Operations
2-96 DG800 User's Guide
System Info
Press Utility System Info, and the model, serial number, and software version
number of the current instrument are displayed in the system information interface.
Option
Press Utility Option, and the installation status of the options for the current
instrument is displayed in the system information interface (for the installation of the
option, refer to "
To Install the Option").
Display Setting
Press Utility DispSet to enter the display setting interface.
1. Brightness Setting
Tap the Brightness parameter input field and use the numeric keypad to
modify the brightness. The range is from 1% to 100%. The default is 50%. This
setting is stored in non-volatile memory and will not be affected by the "restore
to defaults" operation.
2. Screen Saver
Enables or disables the screen saver mode. Tap the Screen Saver parameter
selection field to select "On" or "Off" to enable or disable the screen saver
function. By default, it is set to "Off".
3. Splash Screen
DG800 allows you to self-define the splash screen. You can save the contents
displayed on the screen to the USB storage device in BMP format. Insert a USB
storage device into the USB HOST interface on the rear panel. Tap "Recall" at
the right side of the Splash Screen menu label to enter the store and recall
interface. Select the desired file in BMP format and tap Read.
Note: The internal memory cannot store the file in BMP format. You need to
store the contents in the USB storage device in BMP format first. The size of the
image cannot exceed 480*272.
