To Connect to Power
1. Input power requirement
DP800A series power supply can accept three kinds of AC power supplies:
50Hz–60Hz frequency; 100V, 115V and 230V voltages.
2. Check the voltage selector at the rear panel
Before connecting to power, make sure that the setting voltage of the voltage
selector at the rear panel matches the input voltage.
3. Check the fuse
When the instrument leaves factory, proper fuse is installed. Please check
whether the fuse matches the input voltage according to the “Input Power
Requirement” at the rear panel.
4. Connect the instrument power cord
Connect the instrument to AC power supply using the power cord provided in
the accessories.
To avoid electric shock, make sure that the instrument is correctly
Power-on Inspection
Press the power switch at the front panel and the instrument executes self-test. If
the instrument passes the self-test, the welcome interface will be displayed;
otherwise, the corresponding self-test failure information (including TopBoard,
BottomBoard, Fan and Temperature) will be displayed.
W
hen turn the instrument on again after turn it off, please make sure the time
between the two operations are larger than 5s.
