Internal Memory
Press Storage→Internal to go to the following menu.
Figure 2-75 Table 2-46 The Memory menu
Menu Settings Comments
Internal
Int_00 (S)
Int_01 (S)
.
.
Int_09 (N)
Set up th
e location of files in internal
memory among Int_00 to Int_09.
Thereinto, S in brackets
location has storage file, N indicates has
not.
Recall
Recall waveform files and setup files
from the internal memory location.
Save
Save waveform files and setup files to
the internal memory location.
Delete
File
Delete selected files.
NOTE: To ensure the setups being saved properly, only after the settings are
changed for more than 5 seconds can the user turn off the instrument. The
oscilloscope can store 10 settings permanently and can restore at anytime.
