Declassification Guide for Digital Oscilloscope
5
DS6000 Series
DS6000 series digital oscilloscope consists of DS6104, DS6102, DS6064 and DS6062.
Instrument Memory
This section contains information on the types of memory available in your instrument. It explains the
size of memory, how it is used, its location, volatility and the clearing procedure.
Instrument memory:
Memory
type and
size
Writable
during
normal
operation
Data
retained
when
powered
off
Purpose/
contents
Data
input
method
Location in
instrument
and
remarks
Sanitization
procedure
SDRAM
32MB
Yes No Program Boot Main board
in CPU area
Cycle power
NAND
FLASH
1GB
Yes Yes Internal
savings,
setup/wfm/ref
/pf/trc
Internal
saving
Main board
in CPU area
Save files to
internal C:
NOR
FLASH
16MB
No Yes Firmware, Bin Firmware
update
Main board
in CPU area
No user data
FRAM
2kB
Yes Yes Setting Program Main board
in CPU area
Default
DDR2
32MB*16
B*17
Yes No Acquire
memory
Acquire
system
Main board
in acquire
area
Cycle power
QDR2
22MB*18
B*8
Yes No Display
memory
Display
System
Main board
in draw area
Cycle power
