RIGOL
DS6000 Quick Guide
26
5. Load into the machine cabinet: mount the rack with the instrument fixed to it
into a standard 19-inch machine cabinet with four M6 screws and four M6 square
nuts.
6. Post-installation notice: the rack occupies a height of 6U. The holes pointed out
by the arrows are installation holes. Note that they should be aligned with during
installation.
