DS6000 Quick Guide
20
 System Time: displayed in “hh:mm (hour:minute)” format. When
printing and storing the waveform, the output file will contain this time
message. Press UTIL  System  System Time to set through the
following format:
mm-dd-yyyy hh-mm-ss
(month-date-year hour-minute-second)
 Sound Icon: when sound is turned on, this area displays . Press UTIL
 Sound to turn the sound on or off.
 Battery Icon: when the battery is used for power supply, this area
displays .
 USB flash device: when the oscilloscope detects a USB flash device, this
area displays .
18. Operation MENU
Press any softkey to activate the corresponding menu. The following
symbols might be displayed in the menu:
Denote that on the front panel can be used to select parameter
items. The backlight of turns on when parameter selection is
valid.
Denote that can be used to modify parameter values. The
backlight of turns on when parameter input is valid.
Denote that you can use the Navigation Knob to quickly
adjust/locate parameters.
Denote that can be used to adjust parameters and then press
to select the parameter.
Denote that the current menu has several options.
Denote that the current menu has a lower level menu.
Press this key to return to the previous menu.
Note that the following direction keys might appear in the grid at the
lower-left corner of the menu bar:
Denote that you can turn on the next page menu.
Denote that you can turn on the previous page
menu.
