Rigol DSA1000 Series Accessories User Guide

RIGOL
DSA1000&DSA1000A Options&Accessories
16
Rack Mount Kit
The analyzer could be installed in 19-inch standard machine cabinet, shown below.
1. Kit Parts List
No. Name Qty. Part Number Description
1-1 Front Panel 1 RM-DSA-1-01
1-2 Support Board 1 RM-DSA-1-02
1-3 Left Plate 1 RM-DSA-1-03
1-4 Right Plate 1 RM-DSA-1-04
1-5 Fixed Figure 2 RM-DSA-1-05
1-6 Rear Support Bar 1 RM-DSA-1-06
2-1 M4 Screw 20 RM-SCREW-01 M4*6 Phil-Slot Pan Head
Machine Screw Nail
2-2 M6 Screw 4 RM-SCREW-02 M6*16 Phil-Slot Pan Head
Machine Screw Nail
2-3 M6 Nut 4 RM-SCREW-03 M6*5 Square Machine Female
Screw Contain Lock Blade
2-4 M4 Screw 4 RM-SCREW-04 M4*8 Cross Recessed Pan
Head Screw
