DSA1000&DSA1000A Options&Accessories
7
2. ACP (Adjacent Channel Power)
Measures the power of the main channel and the adjacent channels and
calculates the power difference between the main and each of the adjacent
channels. When enabled, both the span and resolution bandwidth of the analyzer
are adjusted to be smaller automatically.
3. Chan Pwr (Channel Power)
Measures the power and the power density within a specified channel bandwidth.
The span and bandwidth are automatically set to smaller values in this
measurement type.
Main CH BW
Adj CH BW
CH Spacing
Integ BW CH Pwr Span
