Rigol DSA832E User Manual

RIGOL
User’s Guide for DSA800/E Series
XIII
DSA800/E Series Overview
DSA800/E series spectrum analyzers which are small, light and cost-effective, are
portable spectrum analyzers designed for starters. Configured with
easy-to-operate numeric keyboard, high-resolution color LCD display and various
remote communication interfaces, they can be widely used in various fields, such
as education, company research and development as well as industrial
manufacture.
Main features:
 The highest frequency: 1.5 GHz/3.2 GHz/7.5 GHz
 Displayed Average Noise Level (DANL): <-161 dBm (Typical)
 Phase Noise: <-98 dBc/Hz @ 10 kHz offset (Typical)
 Level Measurement Uncertainty: <0.8 dB
 Minimum Resolution Bandwidth (RBW): 10 Hz
 EMI Filter and Quasi-Peak Detector Kit (Option)
 VSWR Measurement Kit (Option)
 AM/FM Demodulation Function
 Various measurement functions (option)
 1.5 GHz Tracking Generator (DSA815-TG)/3.2 GHz Tracking Generator
(DSA832/E-TG)/7.5 GHz Tracking Generator (DSA875-TG)
 8 inch (800×480 pixels) high-definition display with clear, vivid, and
easy-to-use graphical interface
 Various interfaces such as LAN, USB Host, USB Device and GPIB (option)

Rigol DSA832E Specifications

General

Brand	Rigol
Model	DSA832E
Category	Measuring Instruments
Language	English
