RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
2-114
 Domain Server (DNS):
Set the IP address of the DNS server. The format of domain server
address is nnn.nnn.nnn.nnn. Wherein, the range of the first nnn is from 1
to 223 (except 127) and the ranges of the other three nnn are from 0 to
255. It is recommended that you ask your network administor for an
available address. Press DNS and use the numeric keys to input the
desired address.
3. USB
DSA800/E provides a USB Device interface at the rear panel.
Dev Class:
The analyzer may serve as a “slave” device to connect computer or PictBridge
printing device through this interface. You can set the class and address of the
USB slave device. The device classes include Auto Configure, TMC (default)
and Printer.
 Auto Configure: the device class depends on the USB host device.
 TMC: use the analyzer as a Test & Measurement Class device.
 Printer: use the analyzer as a Printer Class device.
Dev Addr:
View the device address. The device address shows the current USB address
and can’t be edited by users.
4. GPIB
Set the GPIB address.
You can modify this parameter using the numeric keys, knob or direction keys.
For more details, please refer to “Parameter Setting”.
Table 2-63 GPIB address
Parameter Explanation
Default 18
Range 0 to 30
Unit N/A
Knob Step
1
Direction Key Step 1
