RIGOL Chapter 1 Quick Start
User’s Guide for DSA800/E Series
connection is in process.
: denote the connection succeeds, the print
finishes or the printer is idle.
: displayed alternatively, denote the print is
in process.
: denote the print has been paused.
7 Print process Show the current print copy and total print copies.
8 USB storage device
status
is displayed when USB storage device is
installed.
9 Operation status Display “Local” (in local mode) or “Rmt” (in remote
mode).
10 Menu title Function of the current menu.
11 Menu items Menu items of the current function.
12 Reference level Reference level.
13 Active function area Current parameter and its value.
14 Attenuator settings Attenuator settings.
15 Trigger level Set the trigger level in video trigger.
16 Display line Reading reference and threshold condition for
peak value display.
17 Average times Average times of trace.
18 Cursor X Current X value of the cursor. Note that X indicates
different physical quantities in different functions.
19 Cursor Y Current Y value of the c
ursor. Note that Y indicates
different physical quantities in different functions.
20 Invalid data Current measured data is invalid as a full sweep
dosen’t complete after the system parameters
have been modified.
21 Menu page number Show the current page number and total number
of pages.
22 Sweep position Current sweep position.
23 Sweep time Sweep time.
24 Span or stop
frequency
The frequency range of the current sweep channel
can be expressed by the combination of center
frequency and span or the combination of start
frequency and stop frequency.
25 Manual setting The corresponding parameter is in manual setting
