Chapter
14
Stor
e and R
ecall
RIGO
L
MSO1000Z/DS1000Z User’s Guide
14
-
13
Acquisiti
on Setting (Acquire)
Acquisition M
ode
Normal
Sin(x
)/x
ON
Memory Dep
th
Auto
Anti
-
Aliasing
OFF
Trig
ger Settin
g (TRIGGER)
Tr
i
g
g
e
r
Ty
p
e
Edge
Source
CH1
Slope
Rising Edge
T
r
igge
r Mode
Auto
Tr
i
gger Cou
pling
DC
T
rigger H
oldof
f
16
ns
No
is
e Rejec
t
OFF
Disp
lay Se
tting (D
isplay)
Displa
y T
ype
V
ectors
Persistence Time
Min
W
aveform Intensit
y
60%
Screen
Grid
Brightness
50%
Signal Source (Source)
[1]
So
urc
e 1 Switc
h
OFF
So
urc
e 2 Switc
h
OFF
Status Displa
y
OFF
Source 1
/
So
urc
e
2
Setup
W
avef
orm
Sine
Channel S
witch
OFF
Fr
equ
enc
y
1.
00 k
Hz
Amplitude
5
.000 V
Offse
t
0.000
μ
V
Start P
hase
0.0°
Modulation
OF
F
Imp
edanc
e
HighZ
Cursor Setting (Cursor)
Mod
e
OFF
Ma
nual
Select
Source
CH1
Cursor
A
-4.000
μ
s
Cursor
B
4.000
μ
s
V
ertical Unit
Source
ww
w.
G
l
o
b
a
l
T
e
s
t
S
u
p
p
l
y
.
co
m
Fi
n
d
Q
ua
li
t
y
P
ro
du
c
ts
O
n
li
n
e
at
:
sa
l
es
@
Gl
ob
a
lT
es
t
Su
p
pl
y
.c
o
m
230
232
Table of Contents
Safety Requirement
4
General Safety Summary
4
Safety Notices and Symbols
6
Allgemeine Sicherheits Informationen
7
Sicherheits Begriffe und Symbole
9
Measurement Category
10
Ventilation Requirement
11
Working Environment
12
Care and Cleaning
14
Environmental Considerations
14
MSO1000Z/DS1000Z Series Overview
16
Document Overview
18
Table of Contents
21
Chapter 1 Quick Start
27
General Inspection
28
Appearance and Dimensions
29
To Prepare the Oscilloscope for Use
30
To Adjust the Supporting Legs
30
To Connect to Power Supply
30
Power-On Inspection
31
To Connect the Probe
31
Function Inspection
33
Probe Compensation
34
Front Panel Overview
35
Rear Panel Overview
36
Front Panel Function Overview
38
Vertical
38
Logic Analyzer
39
Signal Source
39
Horizontal
40
Trigger
41
Clear
41
Auto
41
Run/Stop
42
Single
42
Multifunction Knob
42
Function Menus
43
Print
44
User Interface
45
Parameter Setting Method
50
To Use the Security Lock
51
To Use the Built-In Help System
52
Chapter 2 To Set the Vertical System
53
To Enable the Analog Channel
54
Channel Coupling
54
Bandwidth Limit
55
Probe Ratio
55
Waveform Invert
56
Vertical Scale
56
Amplitude Unit
57
Channel Label
57
Delay Calibration of the Analog Channel
59
Chapter 3 To Set the Horizontal System
61
Delayed Sweep
62
Time Base Mode
63
YT Mode
63
XY Mode
63
Roll Mode
65
Chapter 4 To Set the Sample System
67
Acquisition Mode
68
Normal
68
Peak Detect
68
Average
68
High Resolution
69
Sin(X)/X
70
Sample Rate
70
Memory Depth
72
Antialiasing
73
Chapter 5 To Trigger the Oscilloscope
75
Trigger Source
76
Trigger Mode
77
Trigger Coupling
78
Trigger Holdoff
79
Noise Rejection
79
Trigger Type
80
Edge Trigger
81
Pulse Trigger
82
Slope Trigger
84
Time Setting
85
Video Trigger
87
Pattern Trigger
89
Duration Trigger
91
Timeout Trigger (Optional)
93
Runt Trigger (Optional)
95
Window Trigger (Optional)
97
Delay Trigger (Optional)
99
Setup/Hold Trigger (Optional)
102
Nth Edge Trigger (Optional)
104
RS232 Trigger (Optional)
106
I2C Trigger (Optional)
108
SPI Trigger (Optional)
111
Trigger Output Connector
113
Chapter 6 MATH and Measurement
115
Math Operation
116
Addition
116
Subtraction
117
Multiplication
118
Division
118
Fft
120
AND" Operation
125
OR" Operation
126
XOR" Operation
127
NOT" Operation
128
Intg
129
Diff
130
Sqrt
131
Lg (Use 10 as the Base)
131
Exp
133
Abs
134
Filter
135
Fx Operation
136
Math Operation Label
137
Auto Measurement
138
Quick Measurement after AUTO
138
One-Key Measurement of 37 Parameters
139
Other Parameters
144
Frequency Counter Measurement
145
Measurement Setting
145
To Clear the Measurement
146
All Measurement
148
Statistic Function
148
Measurement History
149
Measurement Result Display Type
149
Cursor Measurement
150
Manual Mode
150
Track Mode
154
Auto Mode
156
XY Mode
157
Chapter 7 Digital Channel
161
To Select the Digital Channel
162
To Turn On/Off the Digital Channel
162
Group Set
163
To Set the Waveform Display Size
164
Reorder Setting
164
Auto View
164
To Set the Threshold
164
To Set the Label
165
Probe Calibration
165
Digital Channel Delay Calibration
165
Chapter 8 Protocol Decoding
167
Parallel Decoding
168
RS232 Decoding (Optional)
173
I2C Decoding (Optional)
178
SPI Decoding (Optional)
181
Chapter 9 Reference Waveform
185
To Enable REF Function
186
To Select REF Source
186
To Adjust REF Waveform Display
186
To Save to Internal Memory
186
To Set the Color
187
To Reset the Reference Waveform
187
To Export to Internal or External Memory
187
To Import from Internal or External Memory
187
Chapter 10 Pass/Fail Test
189
To Enable Pass/Fail Test
190
To Select Source
190
Mask Range
190
Test and Output
191
To Save the Test Mask
192
To Load the Test Mask
192
Chapter 11 Waveform Record
193
Common Settings
194
Playback Option
195
Record Option
196
Chapter 12 Display Control
197
To Select the Display Type
198
To Set the Persistence Time
198
To Set the Waveform Intensity
199
To Set the Screen Grid
199
To Set the Grid Brightness
199
Chapter 13 Signal Source
201
To Output Basic Waveform
202
To Output Sine
202
To Output Square
203
To Output Ramp
204
To Output Pulse
205
To Output DC
205
To Output Noise
206
To Output Built-In Waveform
206
To Output Arbitrary Waveform
210
To Select Waveform
211
To Create Waveform
212
To Edit Waveform
214
Modulation
215
Chapter 14 Store and Recall
219
Storage System
220
Storage Type
220
Internal Storage and Recall
223
External Storage and Recall
224
Disk Management
225
To Select File Type
225
To Create a New File or Folder
226
To Delete a File or Folder
229
To Rename a File or Folder
229
To Clear the Local Memory
229
Factory
230
Chapter 15 Accessibility Setting
237
Remote Interface Configuration
238
LAN Configuration
238
USB Device
241
System-Related
242
Sound
242
Language
242
System Information
242
Vertical Reference
242
Power-Off Recall
243
Self-Calibration
243
Print Setting
244
Aux Output
246
Option Management
247
Auto Options
248
Chapter 16 Remote Control
249
Remote Control Via USB
250
Remote Control Via LAN
254
Chapter 17 Troubleshooting
255
Chapter 18 Specifications
257
General Specifications
264
Calibration Interval
264
Chapter 19 Appendix
265
Appendix A: Accessories and Options
265
Appendix B: Warranty
266
Index
267
Other manuals for Rigol MSO1104Z
Programming Guide
260 pages
Quick Guide
38 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Rigol MSO1104Z and is the answer not in the manual?
Ask a question
