RIGOL Chapter 9 Histogram Analysis
9-4 MSO5000 User Guide
⚫ Sum: indicates the sum of all bins (buckets) in the histogram.
⚫ Peaks: indicates the maximum number of hits in any single bin.
⚫ Max: indicates the maximum value within the histogram range.
⚫ Min: indicates the minimum value within the histogram range.
⚫ Pk_Pk: indicates the Delta between the max. value and the min. value.
⚫ Mean: indicates the average value of the histogram.
⚫ Median: indicates the median value of the histogram.
⚫ Mode: indicates the mode value of the histogram.
⚫ Bin width: indicates the width of each bin (bucket) in the histogram.
⚫ Sigma: indicates the standard deviation of the histogram.
To Reset
Press Reset to reset the statistical data and restart to make statistics.
