RIGOL Chapter 4 To Set the Sample System

4-12 MSO5000 User Guide

it is the screen center. Pressing down the multifunction knob can quickly

reset the user-defined reference position to 0.

Note: This function is unavailable in YT mode with the delayed sweep being enabled,

XY mode, and ROLL mode.
