RIGOL Chapter 2 Functions of the Front Panel
2-46 VNA User Guide
Auto Trig State
Off
Auto Trig
100.000 ms
Trace
Selected Trace
Trace 1
Trace Type
Clear Write
Trace Update
On
Trace Display
Data
Trace Format
S11: Smith Lin/Phase
S21: Log Mag
DTF: Lin Mag(DTF)
Math Function
Off
Window Layout
Four Window (S11); UD Window (S21/DTF)
Meas
Measurement
Function
S11
Meas Setup (S11)
Avg Number
100
Reference Level
0.00 dBm
Aperture Step
Width
10
Port Extension
Off
Port 1 Delay
0.00 ns
Unit
meter
Port 1 Length
0.00 cm
Port 1 Velocity
Factor
0.66
Port 1 Specific Loss
0.00 dB/m
Cal Kits
CK106A
Meas Setup (S21)
Avg Number
100
Ref Value
-10.00 dBm
Aperture Step
Width
10
Port Extension
Off
Unit
meter
Port 1 Delay
0.00 ns
Port 1 Length
0.00 cm
Port 1 Velocity
Factor
0.66
Port 1 Specific Loss
0.00 dB/m
Port 2 Delay
0.00 ns
Port 2 Length
0.00 cm
Port 2 Velocity
Factor
0.66
