Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-47
Port 2 Specific Loss
0.00 dB/m
Cal Kits
CK106A
Meas Setup (DTF)
Avg Number
100
Ref Value
0.00 dBm
Port Extension
Off
Port Delay
0.00 ns
Unit
meter
Port Length
0.00 cm
Port Velocity Factor
0.66
Port Specific Loss
0.00 dB/m
Cal Kits
CK106A
Stop Distance
6.72 m
Velocity Factor
0.66
Cable Loss
0.00 dB/m
FFT Window
Rectangular
Marker
Selected Marker
Marker 1
Marker Type
Position
Reference Marker
Marker 2
Marker Frequency
(Fmax - 10 MHz)/2
Marker Distance
3.36 m
Line State
Off
Marker Table
Off
Peak
Cont Peak
Off
System
[1]
Power On
Preset
Preset Type
Default
LAN Setting Mode
DHCP
HDMI Output
Off
HDMI Resolution
1280*720 60Hz
LCD Switch
On
LCD Backlight
100%
Power Switch
Default
Beep Switch
Off
SCPI Display
On
User Key
Off
Language
English
Note
[1]
: Not affected by Preset settings.
