RIGOL Chapter 2 Functions of the Front Panel
2-50 VNA User Guide
then click the network setting icon . Then, the LAN parameter setting
interface, as shown below, is displayed.
Figure 2-3 LAN Parameter Setting
The following items can be set by the front panel keys, the keyboard shortcut
keys, the externally connected mouse, the touchscreen, or remote operation.
1) Mode
Sets the mode of obtaining the IP address.
⚫ DHCP: When DHCP is selected, the DHCP server assigns network
parameters (such as the IP address, subnet mask, and gateway) to the
analyzer based on the current network configuration.
⚫ Auto: When "Auto" is selected, the instrument will acquire the IP
address ranging from "169.254.0.1" to "169.254.255.254" and the
subnet mask (255.255.0.0) automatically based on the current
network configuration.
⚫ Manual: When "Manual" is selected, you can self-define a desired IP
address for the analyzer.
Note: The analyzer attempts to acquire the IP address configuration
according to the sequence of DHCP, Auto IP, and Manual IP. These three
methods cannot be disabled at the same time.
2) IP
Press IP and use the numeric keys to input the desired IP address.
The format of the IP address is "nnn.nnn.nnn.nnn". The range for the first
segment (nnn) of the address is from 1 to 223 (except 127); and the range
for the other three segments is from 0 to 255. You are recommended to ask
your network administrator for an IP address available.
