Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-51
3) Subnet mask
Press Subnet mask and use the numeric keys to input the desired subnet
mask.
The format of the subnet mask is nnn.nnn.nnn.nnn; wherein, the range of
"nnn" is from 0 to 255. You are recommended to ask your network
administrator for a subnet mask available.
4) Gateway
Press Gateway and use the numeric keys to input the desired gate
address.
The format of the default gateway is "nnn.nnn.nnn.nnn". The range for the
first segment (nnn) of the address is from 1 to 223 (except 127); and the
range for the other three segments is from 0 to 255. You are recommended
to ask your network administrator for a gate address available.
5) DNS
⚫ mDNS: enables or disables the sending of the network information
(including IP address, host name, etc.).
⚫ DNS Mode: Sets the mode of obtaining the DNS address to be
"Manual" or "Auto".
⚫ Preferred DNS: Sets the preferred address for the DNS.
⚫ Backup DNS: Sets the backup address for the DNS.
The format of the DNS address is "nnn.nnn.nnn.nnn". The range for the
first segment (nnn) of the address is from 1 to 223 (except 127); and the
range for the other three segments is from 0 to 255. You are recommended
to ask your network administrator for an address available.
6) Apply
After the LAN interface configuration is finished, press this key to apply the
current configuration to the instrument.
7) Reset
Turns on DHCP and Auto-IP; turns Manual-IP off. Clears the set network
password and restores it to the factory defaults.
2. USB
RSA provides a USB DEVICE interface on the rear panel. The analyzer may serve
as a "slave" device to be connected to the PC via this interface.
Display
Controls the screen display. You can set the current mode, the current measurement
interface or window, and other display-related parameters.
1. HDMI
