RIGOL Chapter 2 Functions of the Front Panel
2-52 VNA User Guide
Enables or disables HDMI.
2. HDMI Resolution
Selects the resolution supported by HDMI interface to be "1280*720 60Hz",
"640*480 60Hz", or "720*480 60Hz ".
3. LCD
Enables or disables LCD. By default, it is On.
Remarks:
⚫ If you are not updating data, turning off LCD can improve the measurement
speed.
⚫ To reduce the electromagnetic radiation of some circuit component, turn off
the LCD.
⚫ To avoid misoperation, turn off the LCD.
4. LCD Backlight
Sets the brightness of the LCD backlight.
The brightness is expressed in percentage. When it is 100, it indicates that the
backlight is the brightest; when it is 1, the backlight is the darkest.
About System
Displays the system information or the option information.
1. System Info
⚫ Model
⚫ Serial Number
⚫ Hardware Version Number
⚫ Firmware Version Number
⚫ Software Version
2. Option Info
Displays the option information.
RSA5000N provides many kinds of options to meet various measurement
requirements. To purchase the corresponding option, please contact RIGOL.
3. Self Test
⚫ Screen
Tests whether the screen has a dot defect by using six colors: blue, red,
green, gray, white, and black. Press any key to switch the screen color and
exit the test.
⚫ Multi-point Touch
Enters the multi-point touch test interface. Use multiple fingers to make
pinch or stretch gestures on the screen, and observe the size of the
