Rigol RSA3015N Quick Guide

RIGOL
14 RSA3000 Quick Guide
English
Basic Operations
Mouse/Keyboard/Touch Screen Operation Rule
Mouse Operation Rule
Connect the mouse (note that only the left-click operation is supported; the
scroll and right-click operations with the mouse are not supported) to the
spectrum analyzer via the USB HOST interface to perform the following
operations:
1. Click to select the menu and window.
2. Press and hold the left mouse button to drag the data displayed on the
graticule or move the slide bar.
3. Double-click the data displayed on the graticule and then the data will be
appeared at the right-corner.
4. Under the Marker function, you can only use the mouse to move a marker,
but unable to add a marker with the mouse.
Keyboard Operation Rule
Connect the keyboard to the spectrum analyzer via the USB HOST interface,
and then use the shortcut keys on the keyboard to perform the same function
as what you do with the front panel keys.
Table 4 Matching Relations between the Front Panel Keys and the Keyboard
Shortcut Keys
Front Panel Key
Keyboard Shortcut Key
[1]
Mode
Alt + o
Mode Setup
[2]
Shift + o
Meas
Alt + e
Meas Setup
[2]
Shift + e
Auto Tune
Ctrl + Alt + a
Preset
Ctrl + Alt + p
FREQ
[2]
Shift + f
SPAN
[2]
Shift + s
AMPT
[2]
Shift + a
BW
[2]
Shift + b
Trace
[2]
Shift + t
Sweep
[2]
Shift + w
