RIGOL
22 RSA3000 Quick Guide
Working Mode Setting
RSA3000 provides three working modes: GPSA, RTSA, and EMI (option). Press
Mode to select the working mode.
Note: In different working modes, the functions of the keys on the front panel
may be different. Press Help to display the help information of the current
working mode. If you need help information for other modes, exit the help
interface first. Then select the desired working mode and obtain the
corresponding help information.
1. GPSA
GPSA adopts two analysis methods: swept and FFT. GPSA can not only
carry out frequency domain analysis, but also time domain (zero span)
analysis.
Select GPSA. In this working mode, you can press Meas to select multiple
measurements..
2. RTSA
RTSA provides the real-time signal analysis function, which can capture
the complex signal seamlessly.
Select RTSA. In this working mode, you can also press Meas to select
multiple measurements.
3. EMI
EMI mode provides the EMI precompatibility measurement function. If
you need this function, please purchase this option (order No.
RSA3000-EMI), and install it according to instructions in "Install the
Option
".
You can also press Mode Setup to open the global parameter setting menu for
the selected working mode under Mode.
