RIGOL
RSA3000 Quick Guide 19
Figure 6 Arrow Keys
4. Use the touch screen
1) Touch the screen to select the function keypad icon
at the
upper-right corner. Then, the function keypad is displayed. Touch
"FREQ";
2) Click Center Freq;
3) Then the numeric keypad is displayed. Input 800, and select the
desired unit "MHz".
5. Use the keyboard
1) Press "Shift + f" to open the Frequency menu;
2) Press "F1" to select Center Freq;
3) Input 800 by using the numeric keys;
4) Press "F2" to select the desired unit (MHz) from the pop-up menu.
For the matching relations between the front panel keys and the keyboard
shortcut keys, refer to Table 4.
6. Use the mouse
1) Click with the mouse to select the function keypad icon
at the
upper-right corner of the screen. Then, the function keypad is
displayed. Click "FREQ";
2) Click Center Freq;
3) Then the numeric keypad is displayed. Input 800, and select the
desired unit "MHz".
