Rigol RSA3015N Quick Guide

RIGOL
RSA3000 Quick Guide 7
English
Figure 1 Front Panel
Table 1 Front Panel Description
No.
Description
No.
Description
1
LCD
9
Numeric keyboard
2
Menu softkeys
10
TG output
[1]
3
Back to previous menu page
11
Utility function key area
4
Function key area
12
Page up/down key
5
Help key
13
Speaker
6
Knob
14
Earphone jack
7
Arrow keys
15
USB HOST
8
RF input
16
Power key
Note
[1]
: This function is only available for RSA3045-TG/RSA3030-TG.
1 2 3 4
5
6
7
16 15 14 13 12 11 10 9 8

Rigol RSA3015N Specifications

General

Brand	Rigol
Model	RSA3015N
Category	Measuring Instruments
Language	English
