9
CRASHCRASH
RIDERIDE TOM3TOM3
TOM2TOM 2 TOM1TOM1
SNARESNARE
BD KICKBD KICK HI-HATHI-HAT HH-CTRLHH-CTRL
MASTER MASTER
OUTOUT
AUX INAUX IN
MIDI OUTMIDI OUT
MIDI INMIDI IN
DC 9V
Caution!
To prevent electric shock and damage to the devices, make sure the
power is switched OFF on the drum and all related device before making
any connection.
Connecting the Pads and Pedals
Using the provided cables, connect each Trigger input jack on the rear
panel of the module and make sure each pad is connected to its
corresponding Trigger input jack.
TO CRASH
TO RIDE
TO HI-HAT
TO TOM1
TO TOM2
TO TOM3
TO SNARE
TO HH-CTRL
TO BD KICK
Electronic Drum
