Rinnai CONTINUUM 2424WC User Manual

Model 2424WCwww.rinnaiamerica.com 44
INSTALLER’S INSTALLATION INSTRUCTIONS
Parts List
Number
116
117
118
119
120
121
125
127
128
129
130
131
132
133
150
151
153
154
400
401
402
403
405
408
Description
Ignition target
Electrode
Flame Rod
Electrode Packing
Electrode Holder
Electrode Sleeve
Heat Exchanger Complete Assy
PCB Bracket
Stop Bracket A
Stop Bracket B
Flue Outlet ( Assy)
Flue Outlet
Flue Outlet Packing
Flue Outlet Packing A
Blower Motor Assy
Fan Casing Assy A
Fan Connection
Fan Connection Packing
Water Inlet ( 3/4” NPT) B
Water Filter Assy
Rectifier
Water Flow Servo & Sensor
120V Anti-Frost Heater
Hot Water Outlet (3/4”NPT) C
Part Number
AU168-325
AU168-321
AU168-322
AU195-312
AH43-262
AU102-681
DU-195-1840
AU195-330
AU195-321
AU195-322
BU169-470
BU169-471
BU169-472
AU155-111-1
BU195-565
BU169-552
BU169-555
AU169-656
H73-511
H73-501-2
M8D1-11
M8E-4-4
BU195-1878
BU132-363-C
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

Rinnai CONTINUUM 2424WC Specifications

General

Brand	Rinnai
Model	CONTINUUM 2424WC
Category	Water Heater
Language	English
