Combustion Specifications
Model: REU-2532-FFU
Item
Gas type Natural Propane
Minimum Btu’s 15,000 15,000
Gas consumption
Maximum Btu’s 180,000 180,000
Upper ∅ 0.95 ∅ 0.75 Injector Diameter
Lower
∅ 1.6 ∅ 1.15
Main Burner B3A7-1
(Lean and Rich Bunsen Burner)
Main Damper
H73-115
Upper: ∅ 6, Lower: (Not used)
Minimum supply 6” W.C 10” W.C
Maximum supply 10.5” W.C 14” W.C
Gas Pressure
Supply/Manifold
Minimum manifold 0.77” W.C 0.93” W.C
