22 Rinnai Tankless Water Heater Installaon and Operaon Manual
3 in./5 in. CONCENTRIC VENT TERMINATIONS
223174PP
223176PP
223177PP
3/5 Condensing Horizontal Terminaon Kit 8.7 in.
3/5 Condensing Horizontal Terminaon Kit 12 in.
3/5 Condensing Horizontal Terminaon Kit 21 in.
5
223186PP 3/5 Condensing Horizontal Diverter
Terminaon Kit 19 in.
16
224047PP 3/5 Condensing Raised Horizontal
Terminaon Kit
24
184162PP 3/5 Condensing Roof Discharge
Terminaon 20 in. above roof
5
196006, 197009 FGV Concentric Vent Kit 3 in. x 20 in.
20
196106, 197107 FGV Concentric Vent Kit 3 in. x 32 in.
20
196116, 197117 FGV Concentric Vent Kit 3 in. x 44 in.
20
52CVKGVS6503 (PVC)/
52CVKGVSF9003 (CPVC)
PVC/CPVC Concentric Vent Kit 3 in. x 20 in.
20
52CVKGVS6503-32 (PVC)/
52CVKGVSF9003-32 (CPVC)
PVC/CPVC Concentric Vent Kit 3 in. x 32 in.
20
52CVKGVS6503-44 (PVC)/
52CVKGVSF9003-44 (CPVC)
PVC/CPVC Concentric Vent Kit 3 in. x 44 in.
20
SC03HT Horizontal Terminaon Adapter
20
SC03VT Vercal Terminaon Adapter
20
ICRT3539 3''/5'' Concentric Roof
Terminaon PPs-UV
20
Direct Vent (Concentric Pipe and Twin Pipe)
1
UBBINK
IPEX
ROYAL
CENTRO
-
THERM
HEAT
-FAB
Manufacturer
Manufacturer
Part Number
Product
Descripon
Diagram
Horizontal
Vercal
Equivalent Length
()
