Rinnai Tankless Water Heater Installaon and Operaon Manual 25
Air Filter Screen N/A
Tee 5
90° Elbow 5
2.5 45° Elbow
VARIOUS 2 in. OR 3 in. SCHEDULE 40 PVC/CPVC TERMINATIONS
Direct Vent (Concentric Pipe and Twin Pipe)
1
3 in. TWIN PIPE TERMINATIONS
ISELL0387UV 3 in. 87° Long PPS-UV
6
ISTT0320 3 in. Terminaon Tee
6
ISLPT0303 3 in. Low Prole Wall Terminaon
5
3PPS-HTPL 3 in. Twin Pipe Terminaon
10
3PPS-HSTL 3 in. Single Horizontal Terminaon
5
3PPS-TBL 3 in. Black UV Resistant Tee
6
196985 FGV PVC Low Prole Terminaon Kit
5
081219 FGV PVC Wall Terminaon Kit
16
52SWVKGVS6503 PVC Side Wall Vent Kits
5
52WTVKGVS6503 PVC Wall Vent Kits
16
CENTROTHERM
DURAVENT
Manufacturer
Manufacturer
Part Number
Product
Descripon
Diagram
Horizontal
Vercal
Equivalent
Length ()
IPEX
ROYAL
