What should the voltage reading be across the Blue and Yellow transformer wires on a Rinnai Indoor Fireplace?
When measuring the voltage across the Blue and Yellow transformer wires of your Rinnai Indoor Fireplace, you should read between 130 and 185 VAC.
What voltage should I read across the Gray to Gray transformer wires on my Rinnai Indoor Fireplace?
When measuring voltage across the Gray to Gray transformer wires on your Rinnai Indoor Fireplace, the reading should be between 110 and 120 VAC.
What voltage should I read across the White to White transformer wires on my Rinnai Indoor Fireplace?
When measuring the voltage across the White to White transformer wires of your Rinnai Indoor Fireplace, you should read between 98 and 105 VAC.
What resistance reading should I get across the Blue and Red sparker board wires on a Rinnai Indoor Fireplace?
When reading resistance across the two lugs where the blue and red wires connect on the sparker board of your Rinnai Indoor Fireplace, you should measure between 100k and 120k ohms.
What should the voltage reading be across the Red to Red transformer wires on a Rinnai Indoor Fireplace?
When measuring the voltage across the Red to Red transformer wires on your Rinnai Indoor Fireplace, you should read between 28 and 50 VAC.
What voltage reading should I see across the Black and Blue transformer wires in my Rinnai Indoor Fireplace?
When measuring the voltage across the Black and Blue transformer wires of your Rinnai Indoor Fireplace, you should read between 10 and 15 VAC.
Device that cuts off gas if unit exceeds predetermined temperature.
Backs up the overheat switch; requires service call to replace.
Cuts off unit (lockout) if flame goes out during operation.
Turns fan on automatically when heat exchanger warms up.
Detailed technical specifications for Rinnai direct vent furnaces.
Specifications for different vent sizes based on wall type.
Procedure for unpacking the 551FA model.
Procedure for unpacking the 1001FA/VA model.
Procedure for converting 1001FA/VA models to natural gas.
Procedure for converting 1001FA/VA models to LP gas.
Instructions for fitting the wall mounting bracket.
Minimum side clearances required for installation.
Procedure for installing sleeve and manifold in standard walls.
Step-by-step guide for operating the RHFE-551FA unit.
Explanation of the unit's control panel and settings.
Procedure for safely turning off gas to the appliance.
Step-by-step guide for operating the RHFE-1001FA/VA unit.
Procedure for safely turning off gas to the appliance.
Steps to follow if the unit does not operate correctly.
Checklist to perform before requesting service.
General recommendations for unit maintenance.
Annual furnace cleaning procedures.
Guidance on checking the flame pattern of the burner.
Electrical wiring schematic for the 1001FA/VA model.
Functional block diagram of the electrical system.
Electrical wiring schematic for the 551FA model.
Functional block diagram of the electrical system.
Important consumer advice regarding heating system checks.
List of parts included in the extension set.
Overview of installing an extension kit for compatibility.
General steps for installing the extension kit.
Caution regarding the maximum extendable length of pipes.
Caution about preventing water condensation in pipes.
Installation instructions for the metal exhaust component.
Installation instructions for the air inlet hose component.
Device that cuts off gas if unit exceeds predetermined temperature.
Backs up the overheat switch; requires service call to replace.
Cuts off unit (lockout) if flame goes out during operation.
Turns fan on automatically when heat exchanger warms up.
Detailed technical specifications for Rinnai direct vent furnaces.
Specifications for different vent sizes based on wall type.
Procedure for unpacking the 551FA model.
Procedure for unpacking the 1001FA/VA model.
Procedure for converting 1001FA/VA models to natural gas.
Procedure for converting 1001FA/VA models to LP gas.
Instructions for fitting the wall mounting bracket.
Minimum side clearances required for installation.
Procedure for installing sleeve and manifold in standard walls.
Step-by-step guide for operating the RHFE-551FA unit.
Explanation of the unit's control panel and settings.
Procedure for safely turning off gas to the appliance.
Step-by-step guide for operating the RHFE-1001FA/VA unit.
Procedure for safely turning off gas to the appliance.
Steps to follow if the unit does not operate correctly.
Checklist to perform before requesting service.
General recommendations for unit maintenance.
Annual furnace cleaning procedures.
Guidance on checking the flame pattern of the burner.
Electrical wiring schematic for the 1001FA/VA model.
Functional block diagram of the electrical system.
Electrical wiring schematic for the 551FA model.
Functional block diagram of the electrical system.
Important consumer advice regarding heating system checks.
List of parts included in the extension set.
Overview of installing an extension kit for compatibility.
General steps for installing the extension kit.
Caution regarding the maximum extendable length of pipes.
Caution about preventing water condensation in pipes.
Installation instructions for the metal exhaust component.
Installation instructions for the air inlet hose component.
