Rinnai S20 User Manual

Rinnai 27 Split Solar OIM
Glass Lined SG175 or SG215 with SGPKIT2C
Items Supplied with Cylinder
1
1
PTR Valve (1000 kPa) 92501190
2
1
Adaptor R ¾ x Rp v
3
3
(1 not
used)
Nipple R ¾
16
2
A
B
Gas Booster Mounting Brackets
1 x tabs bent (A) 26601098
1 x tabs unbent (B) 26601096
ItemsSuppliedwithSGPKIT2C
6
1
Valve Bleed ¾ R S111090
8
1
Tee Brass ¾G x ½G S111091
9
1
Braided Flexihose 225 mm S111092
- 10
Screws 22601048
- 1
Operation and Installation Manual 15401021
ItemsSuppliedwithSGPKIT2C(cont)
11
1
Standard Pump & Controller Assembly S111487
Includes:
• Non return valve 27801713
• Temperature sensor lead 31002710
• Pump 30001755
• Standard Controller S111226
12
1
Temperature Sensor with 2 m lead
Part of Pump and Controller Assembly,
but shown separately for clarity in diagrams
31002710
13
1
Elbow ¾ Rp x ¾ R 21201074
15
1
Braided Flexi Pipe (inc washers) 20001020
- 1
Warranty booklet 15401041
- 1
STC form 15401023
Solar Controller Manual S111415
