Rinnai S20 User Manual

Rinnai 12 Split Solar OIM
SYSTEM
Specications for the various components are shown below.
SystemType
Glass Lined
Cylinders
SG175,SG215,
SE250AB,SE250AM
SE315AB,SE315AM
Glass Lined
Cylinders
SG270SL,SG320SL
All Stainless Steel
Cylinders
160,250,315
Solar ow and return connection: Rp ½ Rp ½ Rp ½
PTR valve connection: Rp ½ Rp ½ Rp ¾
Cold inlet connection: Rp ¾ Rp ¾ Rp ¾
Hot outlet connection: Rp ¾ Rp ¾ Rp ¾
PTR valve setting 1000 kPa 850 kPa 850 kPa
Rating of PTR Valve supplied 10 kW 10 kW 10 kW
Expansion Control Valve (ECV) setting 850 kPa 700 kPa 700 kPa
Max supply pressure with ECV 680 kPa 550 kPa 550 kPa
Max supply pressure without ECV 800 kPa 680 kPa 700 kPa
Pressure limiting valve rating
(supplied by installer if required)
500 kPa 500 kPa 500 kPa
Flow Control
A variable speed pump controls the water ow rate through the collectors and storage cylinder to optimise the
performance of the system�
Solar Controller
There are two types of Rinnai solar controller available for residential solar hot water systems:
•
The Standard Controller is used with all gas boosted systems and electric boosted systems with an
independently controlled element� It should not be used with an electric tank with a mid sensor port�
•
The Deluxe controller is used for systems with an electric element tank that has a mid sensor port�
Both controllers operate of the pump to optimize solar energy collection and stop energy collection when the
cylinder is full of hot water� They both also have the option of Pumped Frost Protection�
The Deluxe controller has the additional functionality of controlling the operation of the electric element for tank
sterilisation and for optimal performance�
For full details see the solar controller manual�
SOLAR COLLECTORS
Full specications for the solar collectors can be found in the installation manual provided in the collector installation
kit� The following information is provided to assist in completing the installation
ENDURO &
EXCELSIOR
ENDURO XL Evacuated Tubes
Potential Solar
Output at PTR
relief conditions
1�25 kW 1�40 kW
20 tubes - 1�30 kW
25 tubes - 1�63 kW
30 tubes - 1�96 kW
Frost Protection
FOR MORE INFORMATION ON
FROST PROTECTION REFER TO
WARRANTY BOOKLET
Power must be on at the pump and the solar controller
must be in Pumped Frost Protection Mode�
See the solar controller manual for more details�
FOR MORE INFORMATION ON FROST
PROTECTION REFER TO WARRANTY BOOKLET
SPECIFICATIONS
SPECIFICATIONS

Rinnai S20 Specifications

General

Brand	Rinnai
Model	S20
Category	Water System
Language	English
