Rinnai Symmetry RDV3611 Installation Guide

26 | RDV3611 Installation Manual: 11156-A 01-12
Wiring diagram (11652-A)
(BROWN)
(RED)
(RED)
(WHITE)
(BLUE)
(RED)
12
11
(BROWN)
FUSE 3A 250V
(GREEN)
CABLE CAT 5
1
2
(Gas Control)
Sparker Earth
Flame Rod
Sparker
5
4
23 1
12
CONTROL PANEL RECEIVER
CONTROL UNIT
IGNITION PACK 579 DBC SIT
FAN MOTOR
10
9
8
7
6
Modulating Coil
50 Hz
High Speed
OH SWITCH
2
1
ACTIVE
NEUTRAL
AC 230V -240V
TEST CONNECTION
Medium Speed
(BROWNN) (BROWN)
(GRN/YLW)
(YELLOW) (YELLOW)
(GREY)
(GREY)
(BLACK)
(BROWN)
(BROWN)
(BLACK)
(BLACK)
(BLUE)
(GRN/YLW)
(BROWN)
(BLUE)
FLAME ROD
(YELLOW)

Rinnai Symmetry RDV3611 Specifications

General

Type	Direct Vent Gas Fireplace
Fuel Type	Natural Gas or Propane
Ignition System	Electronic Ignition
Venting	Direct Vent
Warranty	Limited Lifetime Warranty
Control Type	Remote Control
BTU Input	36, 000 BTU
Log Set	Ceramic Fiber
