4 Value Series Manual
A licensed professional must install the appliance,
inspect it, and leak test it before use. The warranty
will be voided due to improper installaon.
The installer should have skills such as:
gas sizing
connecng gas lines, water lines, valves,
electricity,
knowledge of applicable naonal, state, and
local codes.
installing venng through a wall or roof
If you lack these skills contact a licensed professional.
Installaon Instrucons
Installaon Steps
Prepare for Installaon ...................................... 5
Determine Installaon Locaon ........................ 6
Checklist to Determine Installaon Locaon ... 12
Mount to Wall .................................................. 12
Remove the Front Panel .................................. 12
Installaon of Venng (indoor models only) ... 13
Condensate (indoor models only) .................... 15
Checklist for Venng and Condensate
(indoor models only) ........................................ 15
Installaon of Plumbing ................................... 16
Checklist for Plumbing ..................................... 18
Installaon of Gas Supply ................................ 18
Connect Electricity ........................................... 20
Adjust for High Altude ................................... 20
Adjust for Vent Length (indoor models only) .. 20
Checklist for Gas and Electricity ....................... 20
Installaon of Temperature Controller ............ 21
Final Checklist .................................................. 23
General Instrucons Installer Qualicaons
DO NOT
Do not install the V75i or the V65i outdoors.
Do not install the V75e or the V65e indoors.
Do not install the appliance in an area where water
leakage of the unit or connecons will result in
damage to the area adjacent to the appliance or to
lower oors of the structure. When such locaons
cannot be avoided, it is recommended that a
suitable drain pan, adequately drained, be installed
under the appliance. The pan must not restrict
combuson air ow.
Do not obstruct the ow of combuson and
venlaon air. Combuson air shall not be
supplied from occupied spaces.
Do not use this appliance in an applicaon such as
a pool or spa heater that uses chemically treated
water . (This appliance is suitable for lling large or
whirlpool spa tubs with potable water.)
Do not use substute parts that are not authorized
for this appliance.
MUST DO
The installaon must conform with local codes or,
in the absence of local codes, with the Naonal
Fuel Gas Code, ANSI Z223.1/NFPA 54, or the
Natural Gas and Propane Installaon Code, CSA
B149.1. If installed in a manufactured home, the
installaon must conform with the Manufactured
Home Construcon and Safety Standard, Title 24
CFR, Part 3280 and/or CAN/SCA Z240 MH Series,
Mobile Homes.
The appliance, when installed, must be electrically
grounded in accordance with local codes or, in the
absence of local codes, with the Naonal Electrical
Code, ANSI/NFPA 70, or the Canadian Electrical
Code, CSA C22.1.
The appliance and its appliance main gas valve
must be disconnected from the gas supply piping
system during any pressure tesng of that system
at test pressures in excess of 1/2 psi (3.5 kPa)
(13.84 in W.C.).
Type of installaon
For installaon in residenal applicaons.
Cered for installaon in manufactured (mobile)
homes.
