Rinstrum C510 User Manual

Register Name Type Write Read Read Response Description
5191 SP5 LOCK UINT16 LIV5,,,,,,,,<value>; LIV?5; 5,,,,,,,,<value> Setpoint 5 lock
5192 SP5 ALARM UINT16 LIV5,,,,,,,,,<value>; LIV?5; 5,,,,,,,,,<value> Setpoint 5 alarm
5193 SP5 TIMING UINT16 LIV5,,,,,,,,,,<value>; LIV?5; 5,,,,,,,,,,<value> Setpoint 5 timing
5194 SP5 RESET UINT16 LIV5,,,,,,,,,,,<value>; LIV?5; 5,,,,,,,,,,,<value> Setpoint 5 reset
5201 SP6 TYPE UINT16 LIV6,<value>; LIV?6; 6,<value> Setpoint 6 type
5202 SP6 SOURCE UINT16 LIV6,,<value>; LIV?6; 6,,<value> Setpoint 6 source
5204 SP6 TARGET SINT32 LIV6,,,,<value>; LIV?6; 6,,,,<value> Setpoint 6 target
5206 SP6 INFLIGHT SINT32 LIV6,,,,,<value>; LIV?6; 6,,,,,<value> Setpoint 6 inflight
5208 SP6 HYSTERESIS SINT32 LIV6,,,,,,<value>; LIV?6; 6,,,,,,<value> Setpoint 6 hysteresis
5210 SP6 LOGIC UINT16 LIV6,,,,,,,<value>; LIV?6; 6,,,,,,,<value> Setpoint 6 logic inversion
5211 SP6 LOCK UINT16 LIV6,,,,,,,,<value>; LIV?6; 6,,,,,,,,<value> Setpoint 6 lock
5212 SP6 ALARM UINT16 LIV6,,,,,,,,,<value>; LIV?6; 6,,,,,,,,,<value> Setpoint 6 alarm
5213 SP6 TIMING UINT16 LIV6,,,,,,,,,,<value>; LIV?6; 6,,,,,,,,,,<value> Setpoint 6 timing
5214 SP6 RESET UINT16 LIV6,,,,,,,,,,,<value>; LIV?6; 6,,,,,,,,,,,<value> Setpoint 6 reset
5221 SP7 TYPE UINT16 LIV7,<value>; LIV?7; 7,<value> Setpoint 7 type
5222 SP7 SOURCE UINT16 LIV7,,<value>; LIV?7; 7,,<value> Setpoint 7 source
5224 SP7 TARGET SINT32 LIV7,,,,<value>; LIV?7; 7,,,,<value> Setpoint 7 target
5226 SP7 INFLIGHT SINT32 LIV7,,,,,<value>; LIV?7; 7,,,,,<value> Setpoint 7 inflight
5228 SP7 HYSTERESIS SINT32 LIV7,,,,,,<value>; LIV?7; 7,,,,,,<value> Setpoint 7 hysteresis
5230 SP7 LOGIC UINT16 LIV7,,,,,,,<value>; LIV?7; 7,,,,,,,<value> Setpoint 7 logic inversion
5231 SP7 LOCK UINT16 LIV7,,,,,,,,<value>; LIV?7; 7,,,,,,,,<value> Setpoint 7 lock
5232 SP7 ALARM UINT16 LIV7,,,,,,,,,<value>; LIV?7; 7,,,,,,,,,<value> Setpoint 7 alarm
5233 SP7 TIMING UINT16 LIV7,,,,,,,,,,<value>; LIV?7; 7,,,,,,,,,,<value> Setpoint 7 timing
5234 SP7 RESET UINT16 LIV7,,,,,,,,,,,<value>; LIV?7; 7,,,,,,,,,,,<value> Setpoint 7 reset
5241 SP8 TYPE UINT16 LIV8,<value>; LIV?8; 8,<value> Setpoint 8 type
5242 SP8 SOURCE UINT16 LIV8,,<value>; LIV?8; 8,,<value> Setpoint 8 source
5244 SP8 TARGET SINT32 LIV8,,,,<value>; LIV?8; 8,,,,<value> Setpoint 8 target
5246 SP8 INFLIGHT SINT32 LIV8,,,,,<value>; LIV?8; 8,,,,,<value> Setpoint 8 inflight
5248 SP8 HYSTERESIS SINT32 LIV8,,,,,,<value>; LIV?8; 8,,,,,,<value> Setpoint 8 hysteresis
5250 SP8 LOGIC UINT16 LIV8,,,,,,,<value>; LIV?8; 8,,,,,,,<value> Setpoint 8 logic inversion
5251 SP8 LOCK UINT16 LIV8,,,,,,,,<value>; LIV?8; 8,,,,,,,,<value> Setpoint 8 lock
5252 SP8 ALARM UINT16 LIV8,,,,,,,,,<value>; LIV?8; 8,,,,,,,,,<value> Setpoint 8 alarm
5253 SP8 TIMING UINT16 LIV8,,,,,,,,,,<value>; LIV?8; 8,,,,,,,,,,<value> Setpoint 8 timing
5254 SP8 RESET UINT16 LIV8,,,,,,,,,,,<value>; LIV?8; 8,,,,,,,,,,,<value> Setpoint 8 reset
6001 ERROR SYS UINT32 ESM?0; <value> Error status system (equivalent of
ESR)
6003 ERROR LATCH UINT32 ESM?1; <value> Error status latched (equivalent
of ESR)
6101 UNIT ID STR(15) IDM<value>; IDM?; <value> Unit identification (equivalent of
IDN)
6109 SERIAL NO UINT32 IDM?; ,<value> Unit serial number (equivalent of
IDN)
6111 SW VERSION STR(10) IDM?; ,,<value> Unit software version (equivalent
of IDN)
6116 UNIT MODEL STR(7) IDM?; ,,,<value> Unit model (equivalent of IDN)
6201 WEIGHT DISPLAYED SINT32 MSM?1; <value> Measured displayed weight
(equivalent of MSV)
6203 WEIGHT STATUS DISPLAYED UINT32 MSM?1; ,<value> Measured displayed weight status
6205 WEIGHT GROSS SINT32 MSM?2; <value> Measured gross weight (equivalent
of MSV)
6207 WEIGHT STATUS GROSS UINT32 MSM?2; ,<value> Measured gross weight status
6209 WEIGHT NET SINT32 MSM?3; <value> Measured net weight (equivalent
of MSV)
6211 WEIGHT STATUS NET UINT32 MSM?3; ,<value> Measured net weight status
6213 WEIGHT TOTAL ITEMS SINT32 MSM?4; <value> Measured total number of items
(equivalent of MSV)
6215 WEIGHT STATUS TOTAL ITEMS UINT32 MSM?4; ,<value> Measured total number of items
weight status
6217 WEIGHT TOTAL SINT32 MSM?5; <value> Measured total weight (equivalent
of MSV)
6219 WEIGHT STATUS TOTAL UINT32 MSM?5; ,<value> Measured total weight status
6221 WEIGHT PEAK MAX SINT32 MSM?6; <value> Measured peak maximum weight
(equivalent of MSV)
6223 WEIGHT STATUS PEAK MAX UINT32 MSM?6; ,<value> Measured peak maximum weight
status
6225 WEIGHT LIVEWEIGH SINT32 MSM?7; <value> Measured live weigh weight
(equivalent of MSV)
6227 WEIGHT STATUS LIVEWEIGH UINT32 MSM?7; ,<value> Measured live weigh status
6251 MILLI VOLT PER VOLT SINT32 VAL?; <value> Millivolt per volt reading
6301 PRINT ID UINT32 PRT?0; <value> Print ID
6303 PRINT UINT16 PRT; Print standard printout
100 C500-600-2.0.3
