Rinstrum C510 User Manual

Name Address Type R W Description
Setpoint Jog Off A40C
H
uint32 A A Duration of setpoint jog off time in ms.
Setpoint Jog On A40D
H
uint32 A A Duration of setpoint jog on time in ms.
Setpoint 1 Timing A410
H
uint8 A A Setpoint 1 timing:
0 is level
1 is edge
2 is latch
3 is pulse.
Setpoint 1 Reset A411
H
uint8 A A Setpoint 1 rest:
0 is none
1 is reset A
2 is reset B.
Setpoint Jog Set A412
H
uint8 A A Number of jogs in a set.
Setpoint Max Jog Set A413
H
uint8 A A Maximum number of jog sets. Set to 0 for
unlimited sets.
Setpoint 2 type A421
H
uint8 A A Set setpoint 2 type:
0 is off
1 is on
2 is over
3 is under
4 is centre of zero
5 is zero band
6 is net
7 is motion
8 is error
9 is buzzer
10 is weigh out
11 is weigh in.
Setpoint 2 lock A422
H
uint8 A A Set setpoint 2 lock:
0 is off
1 is on.
Setpoint 2 logic A423
H
uint8 A A Set setpoint 2 logic:
0 is high
1 is low.
Setpoint 2 alarm A424
H
uint8 A A Set setpoint 2 alarm:
0 is none
1 is single beep
2 is double beep
3 is continuous beeping
4 is flash the display.
Setpoint 2 source A426
H
uint8 A A Set setpoint 2 source:
0 is gross weight
1 is net weight.
Setpoint 2 Target A428
H
int32 A A Set setpoint 2 target.
Setpoint 2 Hysteresis A429
H
int32 A A Set setpoint 2 hysteresis.
Setpoint 2 in flight A42A
H
int32 A A Set setpoint 2 in flight.
Setpoint 2 Timing A430
H
uint8 A A Setpoint 2 timing:
0 is level
1 is edge
2 is latch
3 is pulse.
88 C500-600-2.0.3
