10.3. Examples of Operation
The following data loaded :
20120146:D020617420C0206F6E20BF0D0A 
Would produce the printout below:
525 kg N at 11:04 on 03.02.2005<CR><LF>
To use the streaming tokens, the streaming register is first set up as described
above.
Streaming to print the REG_SYSTEM_ERROR, REG_ABSOLUTE_MVV, and
REG_ADC_SAMPLE_NUMBER registers:
Write Stream Register 1
20120042:03


Write Stream Register 2
20120043:04


Write Stream Register 3
20120044:01


The “Streaming Register Raw” print token when loaded :
20120146:E9 
Would produce the printout below on a short press of the print button, auto, single
print, or auto print options:
000000000000138700024AED <CR><LF>
The “Streaming Register Literal” print token when loaded :
20120146:E8 
Would produce the printout below on a short press of the print button, auto, single
print, or auto print options:
E0000,0.4999,148113 <CR><LF>
