12.7. Setup and Calibration Errors
These messages show status messages or errors that may occur during the
instrument setup and calibration.
Error Description Resolution
The instrument may be in Safe
Setup and an item that needs
Full Setup has been selected for
editing.
Access Full Setup to edit the
item.
(ENTRY)
(DENIED)
When accessing setup, more
than three attempts have been
made with the incorrect
passcode.
Turn the instrument off. When
the instrument is turned back on,
enter the correct passcode to
access setup.
(LIN.PT)
(LO)
An attempt has been made to
place a linearisation point below
zero.
Incorrect linearisation point
entered (must be between zero
and full scale).
(PT.TOO)
(CLOSE)
An attempt has been made to
place a calibration point too
close to an existing calibration
point.
Re-enter the calibration point.
Points must be spaced by at least
2% of full scale from each other.
(RES)
(LO)
The scale build is configured for
less than 100 graduations.
Check the resolution (count-by)
and capacity settings.
(RES)
(HIGH)
The scale build is configured for
more than 30,000 graduations.
Check the resolution (count-by)
and capacity settings.
(SPAN)
(LO)
The load cell signal range
(span) is too small for these
settings.
Incorrect span weight entered
(must be between zero and full
scale). Scale wiring incorrect.
Wrong load cell capacity (too
large). Wrong or no calibration
weight added to scale.
(SPAN)
(HI)
The load cell signal range
(span) is too large for these
settings.
Incorrect span weight entered
(must be between zero and full
scale). Scale wiring incorrect.
Load cell capacity too small for
application.
(ZERO)
(LO)
An attempt has been made to
calibrate zero below -2mV/V.
Scale wiring incorrect
(ZERO)
(HI)
An attempt has been made to
calibrate zero above +2mV/V.
Remove all weight from scale.
Scale wiring incorrect.
