Wheelchair Requirements
2. Wheelchair Requirements
The Firey
TM
is compatible with almost all wheelchairs without the need for any special adapters.
Wheelchair
Frame
Conguration
The front tubes of your chair must be similar to one of the three shown
on the next page, specically where the Clamps are installed. For a
complete listing of compatible wheelchairs, visit riomobility.com. If
your wheelchair is not listed, please contact customer service at sales@
riomobility.com.
The Firey
TM
can accommodate chairs of seat width 14” to 20” (35.5cm to
50cm). If your chair is outside this range, contact customer service.
Wheelchair
Frame Tube
Diameter
The frame tube diameter must be either:
1 inch (25.4mm)
1
1
/8 inch
(28.6mm)
1.2 inch (30.5mm)
1¼ inch (31.8mm)
The Firey
TM
ships with a set of 4 Clamps suitable for 1” (25.4mm) tubing.
If your tubing is a dierent diameter, you may order a suitable set of
Clamps on riomobility.com
If you do not know the diameter of your tubing, cut out the ruler
printed below to measure. Wrap it around your tubing and note where
the markings line up. The tube must be straight for the width of the
ruler.
Anti-Tips and
Seatbelts
If the chair is set up such that tipping backwards is easy, it may be
unstable while attaching or detaching the handcycle. To ensure your
safety, anti-tip devices MUST be installed on your wheelchair. A seat
belt is also strongly recommended.
Wheel Locks
Wheelchair must have Wheel Locks installed.
Weight
Combined wheelchair and user weight must be less than 280lb (130kg).
START HERE
1”
1
1
/8”
1.2”
1
1
/4”
RULER MUST BE PRINTED AT 100%
NO SCALING - RULER IS 6” (152mm) LONG
CUT ALONG DASHED LINE
AND WRAP AROUND TUBE
FRAME MUST BE STRAIGHT
FOR WIDTH OF RULER
