Firey Components
3. The Firey
TM
Components
Required tools:
Adjustable Wrench
Pliers
Torque Wrench
Tire Pressure Gauge
Bicycle Pump
Remove the handcycle parts from the box and unpack the components. The contents include:
Handcycle Assembly
Left and Right Wings, including 4 Screws, Lock Washers, Flat Washers, and Nuts
Lithium Battery and Charger
4 Clamps for 1” (25.4mm) tubing size, including 4 Screws, Lock Washers, Flat
Washers, and Pawns
5mm and 8mm Hex Wrench
10/19mm Wrench
2 Cable Ties to secure brake and shift cables, if necessary
1 Reector to attach to the spokes
2 blocks to lift the front wheels during installation
If you are missing any of these items, please contact customer service at sales@riomobility.com
1 Handcycle
2 Wings
3 Battery & Charger
4 Clamps
5 6 7
8 9
