Ripack 2200 - TECHNICAL CHARACTERISTICS; SI and Anglo-Saxon System Specs

8
P
ROPANE GAS APPLIANCE
T ECHNICAL C HARACTERISTICS:
SI system Anglo-Saxon system
pressure 1.5 to 3.5 bar 21 to 50 psi
power 40 to 72 kW 136,000 to 245,000 btu/h
consumption 2.9 to 4.9 kg/h 6.4 to 10.8 lbs/h
air intake 35 to 63 m³/h 1,200 cu.ft/h to 2,200 cu.ft/h
CO emission 0.0046 to 0.0019 % vol
CO2 emission 2.5 to 3.6 % vol
noise levels <85 dbA
length 36 cm 14 inches
weight 1,160 g 2.55 lb
energy source propane
other energy source natural gas with conversion kit
AIR INTAKE
Beginning
of
flame
FLAME STABILISER GRILLE
LIGHTER
VALVE
GAS FILTER
PROPANE
