Risco Lumin8 4012 - Technical Specifications Summary

LuMIN8 Installation Instructions
11
Technical Specification
Single Piezo
Twin Piezo
Input DC Power
Regulated 13.0- 14.2V
Quiescent Current
23mA
23mA
Sounder current
350mA (Regulated)
450mA (Regulated)
Sounder current (Quiet mode)
150mA
180mA
Strobe current
10mA
10mA
Battery charging current
15mA
Speaker Sound level
111dbA
114dbA
Strobe light
Surface Light Technology SMT LED
Strobe lens
Polycarbonate, available in amber, red or blue
Strobe flash rate
60 times per minute (maximum)
Back-up battery (rechargeable)
Ni-MH rechargeable 8.4V, 280mA/h
Ingress Protection
IP65 (For encapsulated PCB),
IP44 (For other sounder components),
IK 08
Operating Temperature
-25°C to 60°C (-13°F to 158°F)
Humidity
95% maximum
Lumin8 Dimensions (W x L x H)
Lumin8 Delta Dimensions (W x L x H)
74mm x 273mm x 230mm
50mm x 277mm x 236mm
Compliance
EN50131-1 Grade 3 Environmental Class IV
